General information

Bike Specifications

SKU

91238f

Year

2026

Frame

Bianchi Arcadex AL, aluminium, hydroformed tubes, tire clearance 50 mm, T47 Bottom bracket, rack and fender compatibility sizes XS- SM-MD-LG-XL

Cassette

Shimano SLX, CS-M7100, 10-51T, 10-12-14-16- 18-21-24-28-33-39-45-51T

Chain

Shimano 105, CN-M7100

Crankset

Shimano GRX, FC-RX610, 40T Crank length: 165 mm (XS-SM); 170 mm (MD-LG); 1725 mm (XL)

Groupset

Shimano GRX, RD-RX822, 12sp

Brakes

Shimano BR-RX410 Hydraulic disc brake

Tyre

Pirelli Cinturato Tanwall, 700x45

Wheels

Velomann V22G, Rim: Aluminium, 622x24c, 24h

Handlebar

Velomann Gravel, Aluminium, diameter 318 mm, reach 70 mm, drop 130 mm, flare 16 deg Size: 400 mm (XS-SM); 420 mm (MD-LG); 440 mm (XL)

Saddle

Selle Royal SRX Open

Seatpost

Velomann Aluminium, 27, 2 mm, Seatback 0 mm length: 300 mm (XS); 350 mm (SM-LG); 400 mm (XL)

Shift Levers

Shimano GRX, shifter lever ST-RX610, caliper BR- RX400

Stem

Velomann AL6061, rise -7° Size: 70 mm (XS); 80 mm (SM); 90 mm (MD); 100 mm (LG); 110 mm (XL)

Bottom Bracket

Token T47, 24 mm axle, 865 mm width

Disk rotors

FRONT: Shimano RT-CL700 Center Lock, 160 mm / REAR: Shimano RT-CL700 Center Lock, 160 mm

Fork

Bianchi Arcadex, Carbon, flat mount disc frake, thru axle 12x100 mm

Headset

Acros for internal cable routing
